300mm SS Screw Conveyor Customized Incline Conveyor With Hopper

Certification : CE, ISO9001:2015

MOQ : 1

Price : US $1,500-2,800 / s

Place of Origin : China

Brand Name : DY

Delivery Time : 7-14 work days

Model NO. : LS-160

Material : Stainless Steel

Material Feature : Heat Resistant

Energy Saving : Energy Saving

Warranty : 1 Year

Color : Multi Color

Condition : New

After-sales Service : Online Video

Length : Customized

Installation : Engineer Guide

Operation : Automatic Continuous Operation

Working Angle : 0-60 Degree

Voltage : 220V/380/as Your Request

Transport Package : Standard Export Wooded Case

Specification : screw diameter 160mm

Trademark : DY

Origin : China

HS Code : 8428399000

Production Capacity : 90 Set/Sets Per Month

Contact Now


Product Description
PRODUCT INTRODUCTION

This screw conveyor is a customizable machine. We can design and manufacture a screw conveyor according to customers' specific requirements. The screw conveyor also be called as other name in different country, for example, sometimes will also named it as pipe screw conveyor; auger conveyor; trough shaped screw conveyor; screw feeder; U-type screw conveyor and so on.

300mm SS Screw Conveyor Customized Incline Conveyor With Hopper
Product Parameters
Model Diameter
(mm)		 The distance of blades(mm) Speed
(rpm)		 Capacity
(t/m³)		 Speed
(rpm)		 Capacity
(t/m³)		 Speed
(rpm)		 Capacity
(t/m³)		 Speed
(rpm)		 Capacity
(t/m³)

D S n φ=0.33 n φ=0.33 n φ=0.33 n φ=0.33
LS100 100 100 140 2.2 112 1.7 90 1.4 71 1.1
LS125 125 125 125 3.8 100 3.0 80 2.4 63 1.9
LS160 160 160 112 7.1 90 5.7 71 4.5 56 3.6
LS200 200 200 100 12.4 80 9.9 63 7.8 50 6.2
LS250 250 250 90 21.8 71 17.2 56 13.6 45 10.9
LS315 315 315 80 38.8 63 30.5 50 24.2 40 13.4
Main Features
  • Small size and rapid rotary speed, which ensures rapid and average conveying.
  • Good sealing quality and rigidity. The outer casing is made of seamless steel pipes, and the end caps are connected with flanges.
  • Modular design and excellent fabricating.
  • Inlets and outlets can be configured as required.
  • Dust-tight housing, high degree of sanitation.
300mm SS Screw Conveyor Customized Incline Conveyor With Hopper
Detailed Photos
300mm SS Screw Conveyor Customized Incline Conveyor With Hopper
Customer Case
300mm SS Screw Conveyor Customized Incline Conveyor With Hopper 300mm SS Screw Conveyor Customized Incline Conveyor With Hopper
Application Industry

Loose materials such as powder, granular and small piece material , which includes: clay powder, pulverized coal, cement, sand, grain, small piece of coal , cobble, and cast iron filings, etc. While it is not applicable for materials with high viscosity and easy to be curdled. Widely applied:It is widely used for the loose cement transportation from cement warehouse to mixer or from cement warehouse to compounding machine in concrete mixing plant

300mm SS Screw Conveyor Customized Incline Conveyor With Hopper
Related Products
300mm SS Screw Conveyor Customized Incline Conveyor With Hopper
300mm SS Screw Conveyor Customized Incline Conveyor With Hopper
300mm SS Screw Conveyor Customized Incline Conveyor With Hopper
Company Profile
300mm SS Screw Conveyor Customized Incline Conveyor With Hopper 300mm SS Screw Conveyor Customized Incline Conveyor With Hopper
FAQ
1).MOQ require?
Our moq is 1 set.(If you need the spare parts,it is also ok).
2).Payment method?
Usually,we accept T/T,Western Union and others, we can't accept D/P,D/A
3).How to guarantee the quality?
If any machine quality problems, we accept return cargos.
Our warrantity is 18 months, promise your 0 risks purchasing
