0-300 Mesh Quartz Screening Gyratory Screen Silica Sand Sieve Machine

MOQ : 1

Price : US $1,600-3,000 / s

Place of Origin : China

Brand Name : DY

Delivery Time : 7-15 work days

Model NO. : PXZS1230

Transmission Structure : Gyratory Screener

Usage : Gyratory Screener for Fertilizer Screening

Works : Gyratory Screener

Object : Granule

Shaft Number : Single

Running Track : Linear Vibrating Screen

Supporting Device : Plate Spring

Warranty : 18months

Customized : Customized

Condition : New

After-sales Service : Online Video

Name : Gyratory Screen for Quartz Silica Sand

Keyword : Gyratory Screen

Material : Carbon Steel/Stainless Steel

Motor : Siemens etc. Brand Motor

Layer(S) : 1-5

Mesh Size : 0-300mesh

Cleaning System : Bouncing Ball Cleaning System

Installation : Engineer Guide

Operation : Automatic Continuous Operation

Transport Package : 20/40 Container

Specification : 1230-2

Trademark : DAYONG

Origin : China

HS Code : 847410000

Production Capacity : 150 Set/Sets Per Month

Contact Now

Gyratory Screen for Quartz Screening Silica Sand Sieve Machine

New plane screening equipment - Plane Gyratory Vibrating Screen

The plane gyratory sieving machine is another new type of sieving equipment developed by the introduction of foreign advanced technology of circular vibration machinery. This machine has the advantages of reasonable design, simple structure, smooth operation, fully enclosed structure, no dust staining, anti-blocking holes, anti-sticky net, etc.. Especially it is more obvious for urea sieving which is highly hygroscopic, sticky, easy to plug holes and sticky net. As the principle of plane rotary motion is adopted, the dynamic ratio of the equipment and the dynamic load of the foundation are effectively reduced. The equipment adopts the plane rotary vibrating screen up and down vibration, there is automatic cleaning equipment under the net, compared with the traditional linear screen, improved screen life, low noise, large screening area, the efficiency of the original 93 ~ 95 increased to 98.5, good prospects for promotion. Plane gyratory sieve machine is mainly for large particles of urea, soda ash, quartz sand screening development of a new type of screening equipment, but also widely used in chemical, food processing, refractory materials, building materials and other industries of screening operations.
0-300 Mesh Quartz Screening Gyratory Screen Silica Sand Sieve Machine

0-300 Mesh Quartz Screening Gyratory Screen Silica Sand Sieve Machine

The plane gyratory sifter is a kind of high standard fine sifter, which is mainly composed of components such as sieve box, driving device, sieve frame, support frame and vibration damping device.

The working principle is to use the ordinary motor to drive the camshaft rotation, so that the screen body for horizontal rotary motion (track for the horizontal circle), does not have the vertical direction of vibration characteristics, does not destroy the original physical properties of the material.

1. No vertical vibration, long screen life (6-12 months).
2. Each layer of the screen is equipped with screen anti-blocking cleaning device. The screen does not block the holes and prolongs the operation cycle. The sifter continuously cleans the screen in working condition.
3. Because of the plane rotary principle, obviously improve the distribution state of the material, so as to improve the effective utilization rate of the screen surface, and finally improve the screening efficiency and reduce the powder content in the finished material.
4. Fully enclosed structure without dust pollution, improve the working environment of operating staff.
5. The dynamic load on the foundation is very small, and the noise is very low.
0-300 Mesh Quartz Screening Gyratory Screen Silica Sand Sieve Machine

Model	Screen Surface Area(mm)	Feeding Size (mm)	Amplitude (mm)	Frequency (r/min)	Motor Model	Power (kW)	Layer
PXZS1225	1200x2500	<15	75-90	1450	Y132S -4	5.5	1-3
PXZS1230	1200x3000	<15	75-90	1450
PXZS1236	1200x3600	<15	75-90	1450
PXZS1525	1500x2500	<15	75-90	1450
PXZS1530	1500x3000	<15	75-90	1450
PXZS1536	1500x3600	<15	75-90	1450
PXZS1830	1800x3000	<20	75-90	750	Y160L -8	7.5
PXZS1836	1800x3600	<20	75-90	750
PXZS1850	1800x5000	<20	75-90	750
PXZS2036	2000x3600	<20	75-90	750
PXZS2050	2000x5000	<20	75-90	750

How to select the right type?

Attention:The selection of screening equipment and your use of demand has a lot to do with the following information you need to provide.

If you have ever used the screen machine Kindly please tell us its DIAMETER,LAYERS,MESH SIZES,MATERIALS.
If never use the machine until now Please offer us the info about material as below:

1.the name of the material.
2.Material characteristics (e.g. specific gravity, bulk density, water content, fluidity, adhesion, electrostatic properties, etc.)
3.the purpose of use (sieving / debris / liquid filtration / media separation)
4.How many layers do you need? Mesh size of each layer?
5.expected processing capacity per hour (Kg/h) In this way,we can precisely choose the matching model for you to meet your use requirements. 6.Voltage(V),Frequency(Hz),Phase(P)

Application Scenario Description

Plane gyratory sieve machine is mainly for large particles of urea, soda ash, quartz sand screening development of a new type of screening equipment, but also widely used in chemical, food processing, refractory materials, building materials and other industries of screening operations.

Common screening materials are:

1. Screening and grading of raw materials and soybean peel in oil and grease plant. 2. Screening and grading of chemical large particle urea, feed plant powder material or granular feed. 3. The initial cleaning of raw materials in feed mills and the grading of intermediate products after the second crushing in large and medium-sized feed mills. 4. grain, heavy alkali, large particle urea, small particle urea, ceramic granules, zirconium oxide, reduced iron titanium powder, barite, food and spices, chemical, plastic, mining, rubber, wood and plywood, medicine, sugar, mining, paper and other industries in the raw materials and finished products screening and grading operations.
0-300 Mesh Quartz Screening Gyratory Screen Silica Sand Sieve Machine

0-300 Mesh Quartz Screening Gyratory Screen Silica Sand Sieve Machine

Our company

With more than 10 years of development and technology precipitation, Our company, Xinxiang Dayong Vibration Equipment Co.,Ltd, has become one professional international manufacturer for sieving machines, vibro sifter machines, ultrasonic sieving clearing systems, separators, vibrating screen machines, conveying equipment, filtration equipment, crushing equipment and so on.

As one of the largest OEM factories in China, each year we supply around 5000 sets machines to serve more than 150 distributors, manufacturers and traders, providing all kinds of reliable customized equipment to help our clients build their brands.
